Self-Contained – Slimline LS

Price range: $3,345.00 through $3,545.00

  • BTU/H: 1704 – 2413
  • Dimensions: Length: 21.5″ , Width: 22.16″ , Height: 10.33″
  • The Quietest , Compact Self Contained Wine Cooling Unit
Description

[et_pb_section fb_built=”1″ _builder_version=”4.16″ custom_padding=”0px||||false|false” collapsed=”off” global_colors_info=”{}”][et_pb_row _builder_version=”4.16″ background_size=”initial” background_position=”top_left” background_repeat=”repeat” width=”100%” custom_padding=”0px||0px||false|false” global_colors_info=”{}”][et_pb_column type=”4_4″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_wc_breadcrumb _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_breadcrumb][et_pb_wc_cart_notice _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_cart_notice][/et_pb_column][/et_pb_row][et_pb_row column_structure=”1_2,1_2″ _builder_version=”4.16″ background_size=”initial” background_position=”top_left” background_repeat=”repeat” width=”100%” custom_padding=”0px||||false|false” global_colors_info=”{}”][et_pb_column type=”1_2″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_wc_images _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_images][/et_pb_column][et_pb_column type=”1_2″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_wc_title _builder_version=”4.18.0″ header_font=”|700|||||||” global_colors_info=”{}”][/et_pb_wc_title][et_pb_wc_rating _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_rating][et_pb_wc_price _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_price][et_pb_wc_description _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_description][et_pb_wc_add_to_cart _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_add_to_cart][et_pb_wc_meta _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_meta][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”4.16″ background_size=”initial” background_position=”top_left” background_repeat=”repeat” width=”100%” global_colors_info=”{}”][et_pb_column type=”4_4″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_tabs _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”][et_pb_tab title=”Description” _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”]

We are happy to announce the first unit in our new luxury series WhisperKool Slimline 2500. The new WhisperKool Slimline 2500 has evolved into a unit that can cool at two capacities at the flip of a switch. We have added centrifugal blowers, which are significantly quieter and can also be set at a medium or low speed, larger coils for greater system capacity, and an improved condensate management system. The controller has been moved to the condenser side of the unit for easier access.

We offer a UV light upgrade to protect your unit from mold and an interchangeable decorative grille to customize the look of your luxury system.

WhisperKool Slimline 2500

The WhisperKool Slimline 2500 is one of our quietest and most compact self-contained cooling units. Slimline units were designed to be mounted in a living area and can be placed in the often-unused space between the cellar door and ceiling.The Slimline fits snugly above your cellar door, out of the way, providing efficient cooling and a low sight profile.

KOOL is convenient.

[/et_pb_tab][et_pb_tab title=”Features” _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”]

  • Self Contained Slimeline LS
  • Through-the-wall installation
  • Condensate Evaporator
  • Two-speed fan switch
  • Up to 45% more capacity
  • UV light upgrade
  • Customizable front panel
  • Quiet and efficient operation
  • Advanced electronic display
  • Liquid-temperature-measuring bottle probe
  • Can be mounted in the often-unused space above a door
  • 30°F temperature differential

[/et_pb_tab][et_pb_tab title=”BTU/H Rating” _builder_version=”4.17.4″ _module_preset=”default” global_colors_info=”{}”]

2396*

Please review all BTU specifications under the “Specifications” tab. The BTU/h value shown here is a theoretical number. There are often circumstances under which a cellar design may require a larger unit due to variables not accounted for in the formula. For example, these variables could be building materials (such as glass, stone, concrete, etc.) which do not offer the insulation capacity required to maintain the optimal cellar environment. We recommend purchasing a unit with a larger capacity to compensate for these unaccounted-for variables. An undersized unit can lead to premature failure and will most likely prevent the cellar from reaching your desired temperature.

[/et_pb_tab][et_pb_tab title=”Specifications” _builder_version=”4.17.4″ _module_preset=”default” global_colors_info=”{}”]

Cellar Size:
Approx. 300 cu. ft. (low fan speed) and 650 cu. ft. (medium fan speed) when cellar is fully insulated and sealed with a proper vapor barrier (each wine cellar is unique and has specific cooling requirements; heat load calculations should always be performed prior to selecting a cooling unit)

BTU/h w/60°F air entering condenser coil:
Low speed fan – 2601/1961 (total/sensible) Medium fan speed – 3032/2413 (total/sensible)

BTU/h w/75°F air entering condenser coil:
Low speed fan – 2635/1951 (total/sensible) Medium fan speed – 2904/2309 (total/sensible)

BTU/h w/85°F air entering condenser coil:
Low speed fan – 2396/1870 (total/sensible) Medium fan speed – 2612/2158 (total/sensible)

BTU/h w/95°F air entering condenser coil:
Low speed fan – 2205/1704 (total/sensible) Medium fan speed – 2392/2008 (total/sensible)

Dimensions:
21.5”L x 22.16”W x 10.33”H
Refrigerant:
R-134a
HP:
1/5
Voltage Rating:
115V (20-amp dedicated circuit required); 230V (subject to availability)
Weight:
81 lbs. without packaging, 90 lbs. with packaging
Amps:
4.3 (running amps)
Drain Line:
1/2” ID clear plastic tubing (not provided)
Installation:
Through the wall (above a doorway)
Thermostat:
Advanced digital controller, liquid-temperature-measuring bottle probe (retractable cable)
Temp. Delta:
Can maintain a 55°F cellar temperature with up to 85°F condenser air intake temperature
Outside Venting:
Not recommended

[/et_pb_tab][et_pb_tab title=”Manuals / Warranty Information” _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”]

[/et_pb_tab][/et_pb_tabs][et_pb_wc_upsells _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_upsells][et_pb_wc_related_products _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_related_products][/et_pb_column][/et_pb_row][/et_pb_section]

Additional information
UV LIGHTING SYSTEM:

No

,

Yes(+$369)
