CS025
Wine Guardian Ceiling Mounted
Split System Cooling Unit
2520 BTU/H
$8,487.00
- BTU/H: 400 – 2480 BTU/h
- Dimensions: Length: 36.5″ , Width: 10.125″ , Height: 9.5″
- Commercial grade, ceiling mounted wine cooling system.
[et_pb_section fb_built=”1″ _builder_version=”4.16″ custom_padding=”0px||||false|false” global_colors_info=”{}”][et_pb_row _builder_version=”4.16″ background_size=”initial” background_position=”top_left” background_repeat=”repeat” width=”100%” custom_padding=”0px||0px||false|false” global_colors_info=”{}”][et_pb_column type=”4_4″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_wc_breadcrumb _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_breadcrumb][et_pb_wc_cart_notice _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_cart_notice][/et_pb_column][/et_pb_row][et_pb_row column_structure=”1_2,1_2″ _builder_version=”4.20.2″ background_size=”initial” background_position=”top_left” background_repeat=”repeat” width=”100%” custom_padding=”0px||||false|false” global_colors_info=”{}”][et_pb_column type=”1_2″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_wc_images _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_images][/et_pb_column][et_pb_column type=”1_2″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_wc_title _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_title][et_pb_wc_rating _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_rating][et_pb_wc_price _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_price][et_pb_wc_description _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_description][et_pb_wc_add_to_cart _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_add_to_cart][et_pb_wc_meta _builder_version=”4.16″ global_colors_info=”{}”][/et_pb_wc_meta][/et_pb_column][/et_pb_row][et_pb_row _builder_version=”4.16″ background_size=”initial” background_position=”top_left” background_repeat=”repeat” width=”100%” global_colors_info=”{}”][et_pb_column type=”4_4″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_tabs admin_label=”Tabs” _builder_version=”4.24.2″ _module_preset=”default” locked=”off” global_colors_info=”{}”][et_pb_tab title=”Description” _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”]
Ceiling Mounted Wine Cellar Cooling Unit is commercial grade, ceiling-mounted coolers for novice or professional wine collectors. The Ceiling Mounted Wine Cellar Cooling Unit is the most installation-friendly and versatile wine cellar cooling units on the market. Many of these features are unique to Wine Guardian and not found in any other type of cooling unit:
-
- Paintable grille to match the decor in your wine cellar
- Certified to Underwriters Laboratory standards
- Split condensing unit keeps cellar quieter
- Recycles warm stale air near the ceiling.
- Easy to install in between ceiling studs
- Specialized fans create ideal airflow
- Extremely quiet operation
- Controls temperature
- Steel mounting flange for 12 or 16-inch gaps
- can heat/cool or cool depending on the unit chosen
- Outdoor enclosure included
- Made in the USA
[/et_pb_tab][et_pb_tab title=”Specifications” _builder_version=”4.17.3″ _module_preset=”default” global_colors_info=”{}”]2480 BTU/H
| SPECIFICATIONS | |
| Width: | 10 3/16″ |
| Top Height: | 9 9/16″ |
| Bottom Height: | 3 3/16″ |
| Depth: | 36 9/16″ |
| Weight: | 51 lbs |
| DBA at 3 feet: | 53 |
| BTUH: | 2900 |
| Full Load AMPS: | 12.2 |
| Electrical: | 115v/1ph/60hz |
| Item: | WRAWGCS025 |
[/et_pb_tab][et_pb_tab title=”Manuals / Warranty” _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”]
 EVAP Cut Sheet (PDF)Condenser Cut Sheet |
|
| Spec Sheet (PDF) Datasheet (PDF) |
|
| Owners Manual (PDF) |
|
| Quick Start (PDF) |
|
| Warranty (PDF) |
[/et_pb_tab][et_pb_tab title=”Options” _builder_version=”4.24.2″ _module_preset=”default” global_colors_info=”{}”]
UPGRADES & ADD-ONS
ELECTRIC HEAT OPTION
Wine Guardian’s electric heat option protects your wine cellar from cold ambient temperatures that dip below the recommended wine storage thresholds.
XTREME LOW AMBIENT PROTECTION
This cold weather protection package allows the SS018 condensing unit to operate in conditions down to -20°F (-29°C) and is recommended in climates where the temperature normally drops to 20°F (-7°C).
FREESTANDING HUMIDIFICATION
Wine Guardian® humidifiers are uniquely designed to deliver superior performance and reliability, ensuring the proper conditions for your wine collection and cellar. Our humidifiers regulate and control humidity while offering the versatility to be used with any brand of wine cooling system.
| Cooling | Air-cooled |
|---|---|
| btu | 400 – 2480 BTU/h |
| kilowatts | 0.12 – 0.73 Kilowatts |
